DECADE MEG-OHM BOX DB-251

Product Description

DECADE MEGOHM BOX (Model No. DB -251)

Portable, Stable Reading & most suitable for Meggar Testing.

Resistance Range : 0.1 MW To 111 GW at 5000 V in 6 Decades X

0.1,1,10, 100 Megohms, 1G & 10 GW

Rated Max. Voltage : 1000V from 0.1 To 100 Mega ohm & 5000V for

100 Meg-ohm and Above.

Dials of 0.1 M, 1M & 10 Meg-ohms can also be used at 5000V when

they are connected in series with high value dial.

Accuracy : ± 5% * Power Rating : 1 Watt at + 50C.

Switches: Specialy designed with thick Fibre glass sheet & nickel

plated contacts.

Note : We also make decade Capacitance/Inductance Box of 6 dial

each. Please ask for specs. & accuracy.
